2016 DMG MORI NT-4300

SPECIFICATIONS

Bar Capacity 3.5”
Chucks Size 1 & 2 12”
Turret Positions 10 All Live
Max Spindle Speed 1&2 3,000 RPM
Max Tool Spindle 12,000 RPM
Max Swing of Workpiece 20.7”
Tool Storage Capacity 100 Tools
Max Rotary Speed 6,000 RPM
Tool Spindle Taper 40

Equipped With:
Siemens 840D w/ CELOS CNC Control
Auto Door
Chip Conveyor Right Side Hinge Type
Super High Pressure Coolant 7.0 mpa
Direct Scale Feedback X Z Y (Tool Spindle / Turret 1 & 2)
High Output Spindle 1 and 2
Renishaw OMP 60 (In Machine Workpiece Measuring)
Mist Collector
Dust Collector
Hume Collector
Air Blow for Tool Tip (Tool Spindle /Turret 2)
Air Blow for Chuck (Spindle 1)
Turret 2 Live Tool Milling Max RPM 6,000
